apollo
8477309000
Max. Product volume | 60 liters |
Dry cycle | 300pc/h |
Screw diameter | 90mm |
Screw L/D ratio | 25 L/D |
Screw drive power | 37 KW |
Screw heating capacity | 18 KW |
No.of heating zone | 4 zones |
Output of HDPE | 150 KG/H |
Servo oil pump drive power | 18.5 KW |
Clamping force | 320 KN |
Template size | 900*900mm |
Max.size of mold | 700X1050mm |
Mold stroke | 550-1200mm |
Max.die diameter | 340mm |
Die heating power | 18 KW |
Die heating segments | 4 zones |
Blowing pressure | 0.8mpa |
Air volume | 1.0 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 90 L/MIN |
Size of machine | 5.2*2.9*4.6 |
Weight of machine | 13.5ton |
