5litre Plastic Jerrycan Making Machine Extrusion Blow Molding Machine 5L 1 Gallon Bottle Blow Molding Machine Price

5litre Plastic Jerrycan Making Machine Extrusion Blow Molding Machine 5L 1 Gallon Bottle Blow Molding Machine Price

Name: 5litre Plastic Jerrycan Making Machine Extrusion Blow Molding Machine 5L 1 Gallon Bottle Blow Molding Machine Price
Rating: 5.0 (5 reviews)

Customization:	Available
Type:	Extrusion Blow Molding Machine
Raw Material:	PE

Quantity:




Inquire Add to Basket

Product Description

Basic Info.

Model NO.

ABLB75II

Making Method of Parison

Extrusion-Blow Molding

Automation

Automatic

Computerized

Certification

CE

Application

Bottles,Jars,Jerry Cans,Gallons,Containers

Max. Product Volume

5L

Die Head

1/2/3/4

Auto-Deflashing

Availalble

Auto-Lubrication

Available

Suitable Material

HDPE/PP/PVC/PETG/PS/LDPE

Guarantee

One Year

Operator Needed

1~2

Production Period

40 Days

Transport Package

Film Packaging

Specification

CE, ISO

Trademark

Apollo

Origin

Jiangsu

HS Code

8477301000

Production Capacity

170~190PCS/H

Product Description

5litre Plastic Jerrycan Making Machine Extrusion Blow Molding Machine 5L 1 Gallon Bottle Blow Molding Machine Price

Automatic bottle making machine
(Double station single die head)
ABLB75 full automatic bottle making machine(Double station single die head) was specially designed for making plastic water bottles, medical bottles, lubricant oil bottles, cosmetic bottles, and other small plastic containers not over 8L. This design is low power consumption and very stable.
The features of this machine:
(1)It is suitable for producing PE, HDPE, PP, PVC, PETG, PS so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 5L.
(2)Single station single die head design, very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.

Technical Parameters: ( ABLB75II)

Max. Product volume	8 L
Out put capacity	*7502 pcs/h**
Screw diameter	75MM
Screw L/D ratio	24:1 L/D
Screw drive power	22 KW
Screw heating capacity	7-8 KW
No.of heating zone	4 zones
Output of HDPE	100 KG/H
Oil pump drive power	7.5 KW
Clamping force	80 KN
Max.size of mold	*400430 MM**
Mold stroke	170-520 MM
Max.die diameter	170 MM
Blowing pressure	0.6 mpa
Air Volume	0.8 M³/MIN
Cooling water pressure	0.3mpa
Water consumption	80 L/MIN
Size of Machine	4.2x2.2x2.7 m
Weight of machine	7.5 Ton
