Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine

Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine

Name: Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine
Rating: 5.0 (56 reviews)

Customization:	Available
Type:	Extrusion Blow Molding Machine
Raw Material:	HDPE

Quantity:




Inquire Add to Basket

Product Description

Basic Info.

Model NO.

ABLD90

Making Method of Parison

Extrusion-Blow Molding

Automation

Automatic

Computerized

Certification

CE

Max.Product Volume

16 L

Screw Diameter

90mm

Screw Drive Power

37kw

Screw Heating Capacity

10kw

Output of HDPE

130 Kg/H

Oil Pump Drive Power

11kw

Clamping Force

160kn

Max.Size of Mold

530*550mm

Template Size

550*550mm

Mold Stroke

320-620mm

Transport Package

Film

Specification

8Ton

Trademark

APOLLO

Origin

Jiangsu China

HS Code

847730100

Production Capacity

10month

Product Description

Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine

ABLD90 full automatic bottle making machine was specially designed for making plastic water bottles, medical bottles, lubricant oil bottles, cosmetic bottles, and other small plastic containers not over 60L. This design is low power consumption and very stable.

The features of this machine:
(1)It is suitable for producing PE, HDPE, PP, PVC, PETG, PS so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 7.5L.
(2)Single station single die head design, very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.

screw diameter	MM	90
Screw L/D ratio	KD/H	24
Screw drive power	KW	27
Max size of mold	MM	*900900**
Output of HDPE	KG/H	150
Clamping force	KN	320

Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine

1. Q: -Can the machine customized only for my products?
  A: - Yes, most APOLLO machines can be customized as per clients' requirements, including the structure special design and brand of parts special request.

2. Q: -How about the molds ?
  A: - APOLLO has its own mold manufacture company for injection and blowing mold. Machine and mold can be tested for samples and smooth matching before shipping. Mold raw material is various  for optional.

3. Q: -What is the business item for this project ?
  A: - a. Delivery Date: within 45 working days after receive the deposit and samples or drawing confirmed by buyer and APOLLO .
        b. Port of Loading: SHANGHAI, CHINA.
        c. Payment: 30% TT deposit, balance before shipment or 100% irrevocable L/C at sight.
        d. Container needed: One 20GP container.

Automatic High Speed Small Plastic 1 5 10 20 25L 30L HDPE Jerry Can Bottle Barrel Extrusion Blow Molding Moulding Making Machine
