120L 150L Milk Plastic Bottle Blowing Machine

Name: 120L 150L Milk Plastic Bottle Blowing Machine
Rating: 5.0 (98 reviews)

Customization:	Available
Type:	Extrusion Blow Molding Machine
Warranty:	12 Months

Quantity:




Inquire Add to Basket

Product Description

Basic Info.

Model NO.

ABLD120

Application

Plastic Medical Head Board

Model Number

Abld 120

Bottle Volume

300 L

After-Sales Services

Available

Output of HDPE

350 Kg/H

Max. Size of Mold

1200X1700 mm

Max. Die Diameter

700 mm

Size of Machine

7.5X3.5X5.5 (Lxwxh)

Product Name

Plastic Medical Head Board Making Molding Machine

Raw Material

HDPE

Making Method of Parison

Extrusion-Blow Molding

Automation

Automatic

Computerized

Certification

CE

Transport Package

Film Package

Specification

300 PC/H

Trademark

APOLLO

Origin

Jiangsu, China

HS Code

84773000

Production Capacity

360PCS/H

Product Description

APOLLO Machinery

ABLD 120

ABLD 120 full automatic extrusion blow molding machine was specially designed for making plastic water bottles, medical bottles, oil bottles, plastic balls, suction tubes and other small plastic containers
not over 250L.
ABLD 120 full automatic extrusion blow molding machine, which we can promise that :
1. Professional after-sale service ,
2. Competetive price,
3. High quality. 120L 150L Milk Plastic Bottle Blowing Machine

Specification:

Name	ABLD 120
Max. product volume	300L
Dry cycle	300PC/H
Screw diameter	120MM
Screw drive power	132 KW
Screw heating capacity	36 KW
Output of HDPE	350 KG/H
Oli pump drive power	37 KW
Clamping force	900KN
Max size of mold	1200×1700 MM
Template size	1200×1600 MM
Max. die diameter	700 MM
Blowing pressure	0.8 MPA
Air volume	1.6M3/MIN
Cooling water pressure	0.3MPA
Water consumption	180 L/MIN
Mold Stroke	880-1700 MM

Main parts of machine:

Electronic Parts
Name	Brand
Micro computer control system	Japanese MITSUBISHI
Tempreture Controller	TAIWAN YANHUA PID
Auxiliary Relay	OMRON
Contactor	Schneider(France)
Electric motor	SImens
Power Source	MEANWELL(Taiwan)
Transudcer	ABB
Hydraulic Parts
Oil pump	HIGH-TECH(Taiwan)
Valve	YUKEN(Japan)
Oil pump and connection	YUKEN(Japan)
Swaled part	HALLITE
Air Control System
Cylinder	AIRTAC
Air Wave	AIRTAC

Packaging & Delivery:
1. Packaging Details:
  Inner package: Film packaging.
Outside package: Wooden cases.

2.Delivery:
Time of Delivery: 35 days after the advance payment.
Mode of payment: T/T, L/C.

Sample Service:
1. The video of how the machine running will be sent to you
2. Welcome to China and to visit our company. We will show you around to see how the machine running.
3. All of us will try our best to help you have a full understanding of our machine so that you can opeate your machine easily and put the machine into use as soon as possible.

After-sale Service:
1. One year warrantly after sale.
2. Provide technical advisory service for a long time.
3. Professional after-sale service.
4. If there is any problem with the machine , or any main parts are broken, we will ask our profesionals and technical personnel to repair it or replace it for free.
5. We will train two or three operating man for free.
   (Travel and hotel is paid by buyer's expenses.)

Q&A:
1. Q: Are you a factory or trading company ?
A; We are a company integrating factory and trade.

2. Q; Where is your company located?
   A; Our company is located in Zhangjiangang, Jiangsu Province,China. It is not far from Ningbo &Shanghai port.Has the extremely advantageous geographical location.

3. Q: Can i visit your company for inspecitng?
   A:Of course, we will try our best to meet your needs. Welcome to visit our company!

Contact Us:
Dear customer,
Thanks for your visiting!! Plastic Medical Head Board Making Molding Machine
APOLLO Machinery is a professional manufacturer for blowing machine . We treat every customer seriously. We will offer the most suitable soluition for you! We are ready to solve the problem for you!
So in order to offer you the best quotation and the most suitable machine , please kindly let us know when you make the inquiry. Such as:
1. What kind of bottle or contanier  you want to make? what's the volume ? Pictures would be helpful!
2. What will you filling into the bottle?
3. What's the capacity you really want?
Looking forward to hearing from you!
Any more questions, please feel free to contact us!
