HDPE Bottles Automatic Blow Molding Machine 10ml to 5L

Name: HDPE Bottles Automatic Blow Molding Machine 10ml to 5L
Rating: 5.0 (88 reviews)

Customization:	Available
Type:	Extrusion Blow Molding Machine
Raw Material:	HDPE

Quantity:




Inquire Add to Basket

Product Description

Basic Info.

Model NO.

ABLB65

Making Method of Parison

Extrusion-Blow Molding

Automation

Automatic

Computerized

Certification

CE

Application

Bottles,Jars,Jerry Cans,Gallons,Containers

Max Bottles This Machine Can Make

5L

Die Head

Single Head and Double Head

Servo Motor

Available

Auto-Deflashing

Available

Auto-Lubrication

Available

Parison Control System

Japan Moog

Power Consumption

25kw

Station Option

Single or Double

Delivery Time

40 Days

Transport Package

Film Packaging

Specification

ISO9001

Trademark

APOLLO

Origin

Zhangjiagang City, Jiangsu Province, China

HS Code

8477301000

Production Capacity

4 Set/Sets Per Month

Product Description

HDPE Bottles Automatic Blow Molding Machine 10ml to 5L

Household Containers Blow Molding Machine 100ml to 3L HDPE Bottles Automatic Blow Molding Machine 10ml to 5L

Full-auto process with High output
New technology for saving energy
CE

Max. Product volume	5 liters
Dry cycle	1100pc/h
Screw diameter	65mm
Screw L/D ratio	24 L/D
Screw drive power	18.5 KW
Screw heating capacity	5-6 KW
No.of heating zone	3 zones
Output of HDPE	80 KG/H
Oil pump drive power	7.5 KW
Clamping force	45 KN
Max.size of mold	148-508mm
Mold stroke	320X360mm
Max.die diameter	140mm
Blowing pressure	0.6mpa
Air volume	0.5 M³/MIN
Cooling water pressure	0.3mpa
Water consumption	40 L/MIN

HDPE Bottles Automatic Blow Molding Machine 10ml to 5L

HDPE Bottles Automatic Blow Molding Machine 10ml to 5L
