Customization: | Available |
---|---|
Warranty: | 1 Year |
Type: | Extrusion Blow Molding Machine |
Quantity: | |
---|---|
Company Profile
Product Description
ABLB90II 4 gallon bottle blow molding machine was specially designed for making plastic water gallons, lubricant oil bottles, tool boxes, plastic drums, and other plastic containers not over 20L.
The features of this machine:Product Parameters
Max. Product volume | 20 liters |
Out put capacity | 2160~2400pc/day |
Screw diameter | 90mm |
Screw L/D ratio | 24 L/D |
Screw drive power | 45KW |
Screw heating capacity | 8 KW |
No.of heating zone | 4 zones |
Output of HDPE | 128KG/H |
Oil pump drive power | 11 KW |
Clamping force | 108KN |
Max.size of mold | 240-660mm |
Mold stroke | 530 X 550mm |
Max.die diameter | 180mm |
Blowing pressure | 0.6 mpa |
Air Volume | 0.9 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 90 L/MIN |
Size of Machine | 4.2x3x3.1m |
Weight of machine | 11ton |
