| Customization: | Available |
|---|---|
| Type: | Extrusion Blow Molding Machine |
| Raw Material: | HDPE |
| Quantity: | |
|---|---|
Max. Product volume | 2000 liters |
Screw diameter | 150mm |
Screw L/D ratio | 33L/D |
Screw drive power | 132KW |
Screw heating capacity | 36 KW |
No.of heating zone | 6 zones |
Output of HDPE | 620-840KG/H |
Oil pump drive power | 75 KW |
Clamping force | 1800 KN |
Max.size of mold | 1730 X 2200mm |
Mold stroke | 1000-2700mm |
Max.die diameter | 1000mm |
Blowing pressure | 1.2 mpa |
Air Volume | 6 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 240L/MIN |
Size of Machine | 11.5x7.5x8m |
Weight of machine | 72 ton |
Max. Product volume | 2000 liters |
Screw diameter | 150mm |
Screw L/D ratio | 33L/D |
Screw drive power | 132KW |
Screw heating capacity | 36 KW |
No.of heating zone | 6 zones |
Output of HDPE | 620-840KG/H |
Oil pump drive power | 75 KW |
Clamping force | 1800 KN |
Max.size of mold | 1730 X 2200mm |
Mold stroke | 1000-2700mm |
Max.die diameter | 1000mm |
Blowing pressure | 1.2 mpa |
Air Volume | 6 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 240L/MIN |
Size of Machine | 11.5x7.5x8m |
Weight of machine | 72 ton |
