| Customization: | Available |
|---|---|
| Type: | Extrusion Blow Molding Machine |
| Raw Material: | HDPE |
| Quantity: | |
|---|---|
| Max. Product volume | 100liters |
| Output capacity | 30~40 pcs/h |
| Screw diameter | 100mm |
| Screw L/D ratio | 25 L/D |
| Screw drive power | 45KW |
| Screw heating capacity | 20KW |
| No.of heating zone | 4 zones |
| Output of HDPE | 160 KG/H |
| Oil pump drive power | 37KW |
| Clamping force | 440 KN |
| Max.size of mold | 800X1000mm |
| Mold stroke | 500-1200mm |
| Max.die diameter | 430mm |
| Die heating power | 9.5KW |
| Die heating segments | 5zones |
| Blowing pressure | 0.8mpa |
| Air volume | 1.2M³/MIN |
| Cooling water pressure | 0.3mpa |
| Water consumption | 100 L/MIN |
| Max. Product volume | 100liters |
| Output capacity | 30~40 pcs/h |
| Screw diameter | 100mm |
| Screw L/D ratio | 25 L/D |
| Screw drive power | 45KW |
| Screw heating capacity | 20KW |
| No.of heating zone | 4 zones |
| Output of HDPE | 160 KG/H |
| Oil pump drive power | 37KW |
| Clamping force | 440 KN |
| Max.size of mold | 800X1000mm |
| Mold stroke | 500-1200mm |
| Max.die diameter | 430mm |
| Die heating power | 9.5KW |
| Die heating segments | 5zones |
| Blowing pressure | 0.8mpa |
| Air volume | 1.2M³/MIN |
| Cooling water pressure | 0.3mpa |
| Water consumption | 100 L/MIN |
